Description

The next generation of mowers from Howard.

Designed for general mowing in a wider variety of applications including parks, sports ovals, reserves, roadsides and turf farms.

Recommended for tractors up to 110hp.

Features

Key Features

• Hot dipped galvanised body
• RLM will handle longer grass than competitive mowers
• Convenient transport lock on RLM237 and RLM350
• Hydraulic safety lock-out on wings of RLM350
• Debris guards front and rear
• Two year gearbox and spindle warranty
• Easy cleaning openings in body
• SG iron housings on roller bearings
• Improved belt engagement on drive pulleys to reduce slipping in heavier grass conditions.
• Adjustable rollers provides precision height control.
• Cutting height indicators for even height settings.

S2 Spindles

• New generation of spindles that’s higher capacity, longer life and stronger all round.
• Waisted housing reduces weight and makes identification of S2 spindle easy.
• Thicker flange at centre to better resist bending.
• Additional cap over top bearing to keep water and debris away from seal lip.
• Higher capacity 6307 sealed bearings from NTN will more than double the bearing life of the original spindle.
• Retrofit design that’s interchangeable with the original spindle. Overall dimensions, mounting holes and blade beam fixings are all identical.

Models

RLM178 – 1.78m Cutting Width
RLM237 – 2.37m Cutting Width
RLM350 – 3.49m Cutting Width

Specifications

Please download the RLM Series Spec Sheet for detailed technical information on this model.

RLM 178
Product Code – HS-RLM178
Overall Width – 1.91m
Cutting Width – 1.78m
Cutting Height – 0-100mm
Tractor Power Required (Approximate) – 30-110hp
Three Point Linkage – Cat 1
Weight – Approx. 460kg

RLM 237
Product Code – HS-RLM237
Overall Width – 2.5m
Cutting Width – 2.37m
Cutting Height – 0-100mm
Tractor Power Required (Approximate) – 45-110hp
Three Point Linkage – Cat 2
Weight – Approx. 800kg

RLM 350
Product Code – HS-RLM350
Hydraulic Folding Wing Design
Width (Overall/Transport) – 3.61m / 2.35m
Cutting Width – 3.49m
Cutting Height – 0-100mm
Tractor Power Required (Approximate) – 75-110hp
Three Point Linkage – Cat 2
Weight – Approx. 1095kg

Manufacturer’s Website

Howard – www.howard-australia.com.au
