Trimax ProCut S5 Rotary Mower at KC Equipment

Description

The Trimax ProCut has been a trusted name in commercial mowing for over 30 years, delivering superior performance across parks, reserves, school grounds, sports fields, and golf courses worldwide. From prestigious locations like Windsor Castle to your local sports fields, the ProCut has set the standard for reliability and quality.

Now, with the release of the ProCut Series 5 in 2023, this renowned mower has been further refined to offer unmatched excellence. The ProCut S5 maintains the market-leading cut and spread quality of its predecessors while eliminating the need for daily maintenance. It’s the ideal solution for a wide range of commercial mowing environments.

The ProCut Series 5 is designed for hassle-free operation. With the introduction of advanced Titan Roller Bearings, all daily greasing requirements have been removed, reducing your maintenance time. The innovative auto-belt tensioning system also reduces belt upkeep while enhancing drive to the spindles, ensuring a cleaner, more consistent cut in all conditions.

For commercial mowing that combines superior performance with easy maintenance, the ProCut Series 5 is the perfect choice. Contact KC Equipment today to learn how this innovative mower can elevate your mowing operations.

Features

Accurate Spindle Setting Technology

• Spindle height is perfectly aligned providing the most accurate cut possible.

Titan Roller Bearing System

• The Trimax Titan roller bearing system is maintenance-free, requiring no regular greasing, and provides excellent retention.

Belt Cavity Dual Wash Flaps

• Provides easy access for removal of grass and drainage of water from belt cavity.

Precise Height Adjustment

• Clearly displayed indicators in both metric and imperial units and high-tensile 1/16″ pitch adjuster for precise cut height alterations.

LazerBladez™

• Achieves a superior cut and finish and is more cost-efficient than reels or solid blade beams.

Full-width Rollers

• Full-width front and rear rollers follow contours and provide excellent anti-scalp protection.

Low Maintenance

• Zero daily maintenance. Spindles, roller bearings and auto-belt tensioning are maintenance-free.

3 Year Warranty

• We aim to build mowers that last and we back this up with a 3 year warranty which also includes the spindles and gearboxes. Our robust design coupled with our experienced service and support network ensures minimum downtime and more productivity.

Product Options

Quattro Blade System

• Four blades (flat, upturned or mixed) per spindle for a finer cut.

Front Mount

• Convenient visibility. Only for tractors with front PTO drive.

Roller Scrapers

• Cleans rollers and reduces clumping in wet conditions.

Anti-Bounce Skids

• Eliminates scalping and bouncing and reduces side channel wear.

Galvanised

• Protect against corrosion in harsh environments.

Storage & Lighting Kit

• LED road lights, safety triangle, and bracket for storage box.

Single Roller

• Allows greater grass intake at the front of the mower.

Nexablades

• Scientifically designed for high-end turf giving a superior cut and spread when it matters most.

Storage Box

• Easy access to spare parts and tools.

Models

ProCut/S5 178
ProCut/S5 210
ProCut/S5 237
ProCut/S5 290

Specifications

ProCut/S5 178
Cutting Width – 1.74m (5’ 8 ½”)
Overall Width – 1.89m (6’ 2 ½”)
Overall Length – 1.44m (4’ 9”)
Height – 1.08m (3’ 6 ½”)
Cut Height Range – 10-110mm (⅜” – 4 ¹⁄₃”)
No. of Blade Spindles – 3
Approx Weight – 492kg (1085lbs)
Minimum PTO Output* – 35hp
Warranty (Years) – 3
Workrate (6 kph) – 1.04 hectares/hr
*Minimum PTO output is a guide only. Requirement varies with the type of work and the terrain.

ProCut/S5 210
Cutting Width – 2.06m (6’ 9”)
Overall Width – 2.21m (7’ 3”)
Overall Length – 1.51m (4’ 11 ½”)
Height – 1.08m (3’ 6 ½”)
Cut Height Range – 10-110mm (⅜” – 4 ¹⁄₃”)
No. of Blade Spindles – 3
Approx Weight – 543kg (1197lbs)
Minimum PTO Output* – 40hp
Warranty (Years) – 3
Workrate (6 kph) – 1.24 hectares/hr
*Minimum PTO output is a guide only. Requirement varies with the type of work and the terrain.

ProCut/S5 237
Cutting Width – 2.32m (7’ 7”)
Overall Width – 2.47m (8’ 1”)
Overall Length – 1.44m (4’ 9”)
Height – 1.08m (3’ 6 ½”)
Cut Height Range – 10-110mm (⅜” – 4 ¹⁄₃”)
No. of Blade Spindles – 4
Approx Weight – 605kg (1334lbs)
Minimum PTO Output* – 45hp
Warranty (Years) – 3
Workrate (6 kph) – 1.39 hectares/hr
*Minimum PTO output is a guide only. Requirement varies with the type of work and the terrain.

ProCut/S5 290
Cutting Width – 2.89m (9’ 6”)
Overall Width – 3.04m (10’)
Overall Length – 1.44m (4’ 9”)
Height – 1.08m (3’ 6 ½”)
Cut Height Range – 10-110mm (⅜” – 4 ¹⁄₃”)
No. of Blade Spindles – 5
Approx Weight – 707kg (1559lbs)
Minimum PTO Output* – 55hp
Warranty (Years) – 3
Workrate (6 kph) – 1.73 hectares/hr
*Minimum PTO output is a guide only. Requirement varies with the type of work and the terrain.
